Vehicle-Mounted Progressing Cavity PUMP

The MJ Verticle-Mounted Pump features a multi-directional wheel base and ergonomic handle, making it suitable for loading/unloading operations in various working conditions.

Flow rate：Q ≤ 200 m3/h (880 USGPM)

Pressure：P ≤ 24 bar (350 psi / 2.4MPa)

Description
Parameter Table
Application
Make an inquiry

Portable Mobility

Lightweight design with swivel casters and ergonomic handrails enables easy relocation, ideal for temporary or on-site transfer tasks across diverse environments.

High Compatibility

Customizable rotor/stator geometries and multiple shaft seal options to adapt to varying media types and industrial processes.

Versatile Deployment

Designed for loading/unloading operations in harsh conditions, including chemical, agricultural, or construction sites.

Robust Construction

Durable base and corrosion-resistant materials ensure long-term reliability even with abrasive or corrosive substances.

Easy Integration

Plug-and-play setup compatible with standard industrial power systems, minimizing installation downtime.

MJ series S-type progressive cavity pump selection table

Pump Model MJ	Max. allowable particle size (mm)	Standard speed n (r/min)	Working pressure P (bar)	Flow/water as the medium Q (m³/h)	Water medium axis power P (kw)
015-02S12	2	200~1000	0~12	0.02~0.52	0.14~0.34
021-02S12	3	200~795	0~12	0.11~1.17	0.16~0.55
031-02S12	4.5	160~630	0~12	0.3~2.88	0.48~1.25
038-02S12	7	160~630	0~12	0.30~7.80	0.9~3.2
045-02S12	8.5	125~500	0-12	0.90~103.8	1.3~4.1
053-02S12	10	125~500	0-12	0.80~18.52	1.7~7.5
063-02S12	17.5	100~400	0-12	0.00~24.8	2.5~9.2
076-02S12	15	100~400	0-12	1.00~41.6	4~16
090-02S12	18	80~315	0-12	4.00~55.37	5.5~20
105-02S12	21	80~315	0~12	6.00~93.05	8~35
125-02S12	25	63~250	0~12	5.00~124.30	11~44
148-02S12	29	63~250	0~12	15.00~208.10	17.5~75

MJ series L-type progressive cavity pump selection table

Pump Model MJ	Max. allowable particle size mm	Standard speed n (r/min)	Working pressure P (bar)	Flow/water as the medium Q (m³/h)	Water medium axis power P (Kw)
015-01L06-	2	160~795	0~6	0.10~0.74	0.1~0.25
021-01L06-	3	160~630	0~6	0.30~1.74	0.25~0.50
031-01L06-	4.5	160~630	0~6	0.90~5.23	0.4~1.1
038-01L06-	7	125~500	0~6	1.50~11.70	0.7~2.75
045-01L06-	8.5	125~500	0~6	3.00~20.60	1.2~4.4
053-01L06-	10	100~400	0~6	4.50~29.10	1.7~5.5
063-01L06-	12.5	100~400	0~6	5.00~49.20	2.4~8.9
076-01L06-	15	80~315	0~6	12.00~65.40	3.5~13
090-01L06-	18	80~315	0~6	15.00~111.00	5.5~24
105-01L06-	21	63~250	0~6	20.00~138.40	8~29
125-01L06-	25	63~250	0~6	43.00~244.90	9~44
148-01L06-	29	63~250	0~6	56.00~411.00	13~57

MJ Vehicle-Mounted pump is suitable for various industries, providing continuous, steady, low-pulsation delivery, and capable of metering nearly any material. Primarily used for mediums with the following characteristics:

● Viscosity from low to high

● Solid particles

● Shear sensitivity

● Lubricating or non-lubricating properties

● Thixotropic and expandable

● Abrasive

● Viscous

such as wastewater, activated sludge, gypsum and cement slurry, acids, limewater, latex paints, soap solutions, and adhesives.

If you have any special requirements or questions that require prior consultation. Please fill out the following form and we will have the specialist contact you as soon as possible.
